當前位置：首頁 » 歐美晶振 » O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

prevnext

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

頻率：JO22H

尺寸：2.50mm x 2.00mm

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器采用高品質壓電晶體與精密振蕩電路,結合Jauch石英晶振專屬的頻率校準技術,實現了優異的頻率穩定度,可有效抑制溫度波動,電壓變化對頻率的影響,確保38.40MHz輸出信號的精準性.2.5V工作電壓下,振蕩器不僅功耗低,還具備快速起振特性,通電后可迅速進入穩定工作狀態,減少藍牙設備的啟動延遲,提升用戶使用體驗.此外,該振蕩器通過嚴苛的質量檢測,長期工作可靠性高,適用于對時鐘精度與穩定性要求嚴苛的藍牙網關,藍牙智能設備等場景,彰顯Jauch品牌的品質保障.

訂購熱線：0755-27876565

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

O38.40-JO22H-E-2.5-1-T1-LF是Jauch品牌專為無線藍牙設備設計的高頻振蕩器,核心頻率精準鎖定38.40MHz,完美匹配藍牙通信協議對時鐘信號的頻率要求,能為藍牙模塊提供穩定的載波頻率基準,保障數據傳輸的速率與準確性.其適配2.5V工作電壓,符合藍牙設備低功耗設計需求,可有效降低模塊能耗,延長藍牙設備(如無線耳機,藍牙音箱)的續航時間.同時,作為Jauch旗下產品,該振蕩器依托品牌成熟的制造工藝,具備出色的頻率穩定度,即使在藍牙設備頻繁啟停或信號切換時,仍能維持頻率穩定,避免通信中斷或數據丟包,是無線藍牙晶振設備的核心時鐘組件.

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

原廠型號 Originalmodel：	O 38.40-JO22H-E-2.5-1-T1-LF	品牌brand：	Jauch振蕩器
Manufacturer品牌	Jauch振蕩器	OperatingTemperature溫度	-40°C ~ 85°C
Series型號	JO22H	Current-Supply(Max)	6mA
Type類型	XO (Standard)	PackageHeight高度	1.00mm
Frequency頻率	38.4 MHz	Termination 腳位	4-pad
輸出方式 Output：	HCMOS	PackageType 封裝類型	4-SMD
Voltage-Supply電壓	2.5V	Packaging 包裝	TapeandReel
FrequencyStability頻率穩定度	±15ppm	安裝方式 Installation：	Surfacemount
Size/Dimension尺寸	2520貼片晶振	最小包裝數MPQ：	3000

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

JO22H-

O38.40-JO22H-E-2.5-1-T1-LF,無線藍牙應用晶振,Jauch振蕩器

J49SML-A-G-G-K-16M0	Jauch無源晶振	J49SML	MHz Crystal	16 MHz	±30ppm	±30ppm	12pF
J49SML-A-G-G-K-4M0	Jauch無源晶振	J49SML	MHz Crystal	4 MHz	±30ppm	±30ppm	12pF
J49SML-F-G-G-K-16M0	Jauch無源晶振	J49SML	MHz Crystal	16 MHz	±30ppm	±30ppm	18pF
J49SML-F-G-G-K-25M0	Jauch無源晶振	J49SML	MHz Crystal	25 MHz	±30ppm	±30ppm	18pF
J49SML-F-G-G-K-8M0	Jauch無源晶振	J49SML	MHz Crystal	8 MHz	±30ppm	±30ppm	18pF
Q 27.120-JXS22-10-10/10-FU-LF	Jauch無源晶振	JXS22	MHz Crystal	27.12 MHz	±10ppm	±10ppm	10pF
Q 38.40-JXS21-8-10/10-FU-LF	Jauch無源晶振	JXS21	MHz Crystal	38.4 MHz	±10ppm	±10ppm	8pF
Q 38.40-JXS21-9-10/15-T1-FU-LF	Jauch無源晶振	JXS21	MHz Crystal	38.4 MHz	±15ppm	±10ppm	9pF
Q 27.120-JXS21-12-10/15-T1-FU-LF	Jauch無源晶振	JXS21	MHz Crystal	27.12 MHz	±15ppm	±10ppm	12pF
Q 26.0-JXS11-12-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	26 MHz	±10ppm	±10ppm	12pF
Q 32.0-JXS11-8-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	32 MHz	±10ppm	±10ppm	8pF
Q 50.0-JXS11-8-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	50 MHz	±10ppm	±10ppm	8pF
Q 32.0-JXS11-10-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	32 MHz	±10ppm	±10ppm	10pF
Q 27.120-JXS11-8-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	27.12 MHz	±10ppm	±10ppm	8pF
Q 38.40-JXS22-8-10/10-FU-LF	Jauch無源晶振	JXS22	MHz Crystal	38.4 MHz	±10ppm	±10ppm	8pF
Q 50.0-JXS11-12-10/20-T1-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	50 MHz	±20ppm	±10ppm	12pF
Q 27.120-JXS11-8-10/20-T1-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	27.12 MHz	±20ppm	±10ppm	8pF
Q 32.0-JXS11-10-10/20-T1-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	32 MHz	±20ppm	±10ppm	10pF
Q 38.40-JXS22-10-10/15-T1-FU-LF	Jauch無源晶振	JXS22	MHz Crystal	38.4 MHz	±15ppm	±10ppm	10pF
J49SML-F-G-G-K-4M0	Jauch無源晶振	J49SML	MHz Crystal	4 MHz	±30ppm	±30ppm	18pF
J49SML-P-G-G-K-12M0	Jauch無源晶振	J49SML	MHz Crystal	12 MHz	±30ppm	±30ppm	30pF
J49SML-A-G-G-K-12M0	Jauch無源晶振	J49SML	MHz Crystal	12 MHz	±30ppm	±30ppm	12pF
Q 19.20-JXS32-12-10/10-LF	Jauch無源晶振	JXS32	MHz Crystal	19.2 MHz	±10ppm	±10ppm	12pF
Q 40.0-JXS11-12-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	40 MHz	±10ppm	±10ppm	12pF
Q 40.0-JXS11-10-10/10-FU-LF	Jauch無源晶振	JXS11	MHz Crystal	40 MHz	±10ppm	±10ppm	10pF
J49SMH-C-G-G-K-16M0	Jauch無源晶振	J49SMH	MHz Crystal	16 MHz	±30ppm	±30ppm	20pF
J49SMH-B-G-G-K-14M74560	Jauch無源晶振	J49SMH	MHz Crystal	14.7456 MHz	±30ppm	±30ppm	16pF
J49SMH-P-G-G-K-10M0	Jauch無源晶振	J49SMH	MHz Crystal	10 MHz	±30ppm	±30ppm	30pF
J49SMH-B-G-G-K-27M0	Jauch無源晶振	J49SMH	MHz Crystal	27 MHz	±30ppm	±30ppm	16pF
J49SMH-P-G-G-K-18M4320	Jauch無源晶振	J49SMH	MHz Crystal	18.432 MHz	±30ppm	±30ppm	30pF
J49SMH-P-G-G-K-6M0	Jauch無源晶振	J49SMH	MHz Crystal	6 MHz	±30ppm	±30ppm	30pF
J49SMH-C-G-G-K-8M0	Jauch無源晶振	J49SMH	MHz Crystal	8 MHz	±30ppm	±30ppm	20pF
J49SMH-P-G-G-K-4M91520	Jauch無源晶振	J49SMH	MHz Crystal	4.9152 MHz	±30ppm	±30ppm	30pF
J49SMH-B-G-G-K-6M0	Jauch無源晶振	J49SMH	MHz Crystal	6 MHz	±30ppm	±30ppm	16pF
J49SMH-C-G-G-K-20M0	Jauch無源晶振	J49SMH	MHz Crystal	20 MHz	±30ppm	±30ppm	20pF
J49SMH-B-G-G-K-4M0	Jauch無源晶振	J49SMH	MHz Crystal	4 MHz	±30ppm	±30ppm	16pF
J49SMH-P-G-G-K-3M579545	Jauch無源晶振	J49SMH	MHz Crystal	3.579545 MHz	±30ppm	±30ppm	30pF
J49SMH-P-G-G-K-7M37280	Jauch無源晶振	J49SMH	MHz Crystal	7.3728 MHz	±30ppm	±30ppm	30pF
J49SMH-B-G-G-K-8M0	Jauch無源晶振	J49SMH	MHz Crystal	8 MHz	±30ppm	±30ppm	16pF
J49SMH-B-G-G-K-4M91520	Jauch無源晶振	J49SMH	MHz Crystal	4.9152 MHz	±30ppm	±30ppm	16pF
J49SMH-P-G-G-K-3M68640	Jauch無源晶振	J49SMH	MHz Crystal	3.6864 MHz	±30ppm	±30ppm	30pF
J49SMH-F-G-G-K-30M0	Jauch無源晶振	J49SMH	MHz Crystal	30 MHz	±30ppm	±30ppm	18pF
Q 30.0-JXS32P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS32P4	MHz Crystal	30 MHz	±20ppm	±20ppm	12pF
Q 26.0-JXS32P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS32P4	MHz Crystal	26 MHz	±20ppm	±20ppm	12pF
Q 32.0-JXS32P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS32P4	MHz Crystal	32 MHz	±20ppm	±20ppm	12pF
Q 24.0-JXS32P4-8-20/20-T1-FU-AEC- LF	Jauch無源晶振	JXS32P4	MHz Crystal	24 MHz	±20ppm	±20ppm	8pF
Q 25.0-JXS32P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS32P4	MHz Crystal	25 MHz	±20ppm	±20ppm	12pF
Q 27.0-JXS21P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS21P4	MHz Crystal	27 MHz	±20ppm	±20ppm	12pF
Q 30.0-JXS22P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS22P4	MHz Crystal	30 MHz	±20ppm	±20ppm	12pF
Q 26.0-JXS21P4-8-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS21P4	MHz Crystal	26 MHz	±20ppm	±20ppm	8pF
Q 24.0-JXS22P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS22P4	MHz Crystal	24 MHz	±20ppm	±20ppm	12pF
Q 27.0-JXS22P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS22P4	MHz Crystal	27 MHz	±20ppm	±20ppm	12pF
Q 32.0-JXS21P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS21P4	MHz Crystal	32 MHz	±20ppm	±20ppm	12pF
Q 24.0-JXS21P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS21P4	MHz Crystal	24 MHz	±20ppm	±20ppm	12pF
Q 48.0-JXS21P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS21P4	MHz Crystal	48 MHz	±20ppm	±20ppm	12pF
Q 48.0-JXS32P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS32P4	MHz Crystal	48 MHz	±20ppm	±20ppm	12pF
Q 48.0-JXS22P4-12-20/20-T1-FU-AEC-LF	Jauch無源晶振	JXS22P4	MHz Crystal	48 MHz	±20ppm	±20ppm	12pF
Q 0.032768-JTX110-12.5-20-T1-90K-LF	Jauch無源晶振	JTX110	kHz Crystal	32.768 kHz	-	±20ppm	12.5pF
Q 0.032768-JTX110-9-20-T1-90K-LF	Jauch無源晶振	JTX110	MHz Crystal	32.768 kHz	-	±20ppm	9pF
J31SMT-A-D-K-32K768	Jauch無源晶振	JT31SMT	kHz Crystal	32.768 kHz	-	±20ppm	12.5pF
